Tekniska specifikationer för CAN-enheter

Tekniska specifikationer för USB CAN-bussgränssnitt

DS-CAN2SIRIUSim-4xCANSIRIUSi-8xCANSIRIUSif-8xCANSIRIUSiw-8xCANKRYPTONi-2xCAN USB
CAN ports specification
Number of ports248 + 18 + 18 + 12
Interface typeCAN 2.0BCAN 2.0BCAN 2.0BCAN 2.0BCAN 2.0BCAN 2.0B
Interface data rateup to 1 Mbit/secup to 1 Mbit/secup to 1 Mbit/secup to 1 Mbit/secup to 1 Mbit/secup to 1 Mbit/sec
Special protocolsOBDII, J1939, CAN outOBDII, J1939, CAN outOBDII, J1939, CAN outOBDII, J1939, CAN outOBDII, J1939, CAN outOBDII, J1939, CAN out
Galvanic isolation (Sensor supply not isolated)IsolatedIsolatedIsolatedIsolatedIsolatedIsolated
Bus pin fault protection±36 V±36 V±36 V±36 V±36 V±36 V
Power specification
Power supply6 - 36 V DC Startup voltage 7 VMax voltage 5.00 V ±0.25 V 2x USB 2.0 powered9 - 36 V DC9 - 36 V DC9 - 36 V DC6 - 50 V DC Startup voltage 7 V
Maximum sensor power consumption 3 W max total (max 2 W on 15 V)2.5 W max total1 W per channel1 W per channel5 W max total (max 3 W on 15 V)
Maximum power consumption 5.5 W5 W Combined device & sensor consumption6.5 W (instrument) + 8 W (sensor)6.5 W (instrument) + 8 W (sensor)5.5 W
Environmental specification
InterfaceUSB 2.0USB 2.0USB 2.0USB 2.0USB 2.0EtherCAT
Connector type 9 pin D-SUB9 pin D-SUB9 pin D-SUB9 pin D-SUB9 pin D-SUB9 pin D-SUB
Physical dimensions 105 x 90 x 30 mm 3.94 x 3.54 x 1.18 inch145 x 139 x 64 mm 5.71 x 5.43 x 2.52 inch266 x 139 x 64 mm 10.47 x 5.43 x 2.52 inch266 x 139 x 64 mm 10.47 x 5.43 x 2.52 inch282 x 135 x 70 mm 11.10 x 5.47 x 2.76 inch213 x 54 x 56 mm (slice) 213 x 54 x 71 mm (with connectors)
WeightWeight 230 g 0.51 lbsWeight 800 g 1.76 lbs1320 g 2.90 lbs1320 g 2.90 lbs1930 g 4.25 lbs575 g 1.27 lbs
Operating temperature -20°C to +60°C-10°C to +50°C-10°C to +50°C-10 °C to +50 °C-40 °C to +60 °C-20 °C to +60 °C
Storage temperature -40°C to +70°C-40°C to +70°C -40°C to +70°C -40 °C to +70 °C -40 °C to +70 °C-40 °C to +70 °C
Humidity5 to 95 % RH non-condensing at 50 °C5 to 95 % RH non-condensing at 50 °C5 to 95 % RH non-condensing at 50 °C5 to 95 % RH non-condensing at 50 °C-5 to 95 % RH non-condensing at 50 °C
IP protectionIP50IP50IP20IP50IP65 / IP67IP50
Rev: 1620302400

Tekniska specifikationer för EtherCAT® CAN-bussgränssnitt

KRYPTONi-1xCANKRYPTONi-1xCAN-FDIOLITEi-4xCAN-FD
CAN ports specification
Number of ports114
Interface typeCAN 2.0BCAN-FD, CAN 2.0BCAN-FD, CAN 2.0B
Interface data rateup to 1 Mbit/secup to 5 Mbit/secUp to 1 Mbit/s (CAN2.0B) Up to 5 Mbit/s (CAN-FD)
Special protocols J1939 (see 1)J1939 (see 1)J1939 (see 1)
Galvanic isolationIsolatedIsolatedIsolated
Bus pin fault protection±28 V±36 V
Power specification
Power supply9 - 50 V DC9 - 50 V DC9 - 48 V DC
Maximum sensor power consumption 5 V / max. 250 mA (1.25 W) 12 V / max. 90 mA (1.1 W)5 V / max. 250 mA (1.25 W) 12 V / max. 90 mA (1.1 W)5 V / max. 250 mA (1.25 W) 12 V / max. 90 mA (1.1 W)
Maximum power consumption max. 2 W (no load)max. 2 W (no load)
Environmental specification
InterfaceEtherCAT, 100 Mbit/s Lemo 1T (1 cable for data, power and sync, daisy chainable) EtherCAT, 100 Mbit/s Lemo 1T (1 cable for data, power and sync, daisy chainable) EtherCAT, 100 Mbit/s
Connector type DSUB-9DSUB-99 pin D-SUB
Physical dimensions 62 x 56 x 29 mm62 x 56 x 29 mm128.4 x 118.4 x 30.14 mm
Weight200 g 0.44 lbs200 g 0.44 lbs200 g 0.44 lbs
Operating temperature -40 °C to +85 °C-40 °C to +85 °C-10 °C to +50 °C
Storage temperature -40 °C to +85 °C-40 °C to +85 °C-40 °C to +85 °C
Humidity---
IP protectionIP65 / IP67IP65 / IP67-
1) Transmit mode not supported yet. OBDII and XCP plugins not supported yet.
Rev.: 1671516000
